D13461-1
Note:Optimumtransducerlocationwill
varydependingonvesseltype.Optimum
transducerheightandangleshouldbe
obtainedbytestingthetransducerwiththe
vesselinthewater.
Transducerdimensions—CPT-S
65.5 mm (2.58 in)
86 mm (3.39 in)
111.6 mm (4.39 in)
D13466-1
•CPT-Scablelength:10m(32.8ft).
Planningtheinstallation
17
