FLIRTA72_TA74USERMANUALDocumentIdentifier:TA72_TA74en‐US_AC

7.2ACCurrentElectricalspecifications

Function Range OutputVoltage Accuracy

ACCurrent



30.00AAC 100mV/1AAC

±(3.0%ofFullScale)

forfrequencyrange:45~500Hz

300.0AAC 10mV/1AAC

3000AAC 1mV/1AAC

Notes:

Accuracyisgivenas±(%ofreading+leastsignificantcounts)at73.4F±9F(23C±5C)with

relativehumiditylowerthan80%.Accuracyisspecifiedforaperiodofoneyearaftercalibration.

Max.OutputVoltage:4.5Vpeak

OutputNoise:<5mVforeachrange



PositionErrorofClamp:Accuracyandpositionerrorassumescentralizedprimaryconductorat

optimumposition(centerofclampjaw),noexternalelectricalormagneticfield,andwithin

operatingtemperaturerange.

Distance

from

optimum

position

TA72 TA72Error TA74 TA74Error Position*

0.6”(15mm) 2.0% 1.4”(35mm) 1.0% A

1.0”(25mm) 2.5% 2.0”(50mm) 1.5% B

1.4”(35mm) 3.0% 2.4”(60mm) 2.0% C

*Seepositionexamplesindiagrambelow:



Fig.7‐1PositioningConductorinClampJawcenter
