4. Descriptions

4.1MeterDescription
1. FlexibleCurrentClampCoil
2. WorkLights
3. Coiltip(insertsintolockmechanism)
4. Clamplockmechanism
5. Rangeindicators
6. RANGEselectbutton
7. PowerandWorkLightsbutton
8. Testleadcableconnection
9. TestleadsconnecttoDMM
Notethatbatterycompartmentislocatedonthe
backofthemeter

