Floe VSD 5000 - Assembly of Step 4

NOTE
DO NOT ALLOW LEG
TO FALL INSIDE
CORNER POST.
Assembly of Step 4
4
-
C
4
-
B
4
-
A
NOTE
MAKE SURE HOLES IN
BALL SCREW ARE
ALIGNED WITH
HOLES IN CLAMP
AND BEARING
BLOCK.
111-04306-01
ASS’Y, BALL SCREW
CLAMP – 3” POST
