Floe VSD 5000 - Page 20

4
-
D
4
-
E
4
-
F
4
-
G
NOTE
PULL CABLE OUT
OF BALL SCREW
TUBE PRIOR TO
PLACING
BETWEEN
CORNER POSTS.
NOTE
MAKE SURE HOLES IN BALL SCREW ARE ALIGNED WITH HOLES IN
CLAMP
AND BEARING BLOCK.
