SPECIFICATIONS
TM05 -
1/2 INCH
TM07 -
3/4 INCH
TM10 -
1 INCH
TM15 -
1-1/2 INCH
TM20 - 2 INCH
Type Turbine Flowmeter
Unit of
Measure
Gallon or Litre
Flow Range
1-10 GPM
3.8-38 L/min
2-20 GPM
7.6-76 L/min
5-50 GPM
19-190 L/min
10-100 GPM
38-380 L/min
20-200 GPM
76-760 L/min
Accuracy w/
Computer
+/- 3.0% of Reading (Accuracy can be improved with eld calibration)
Max.
Working
Pressure
225 PSIG @ 73°F (15.5 bar @ 23°C);
BSP - 150 PSIG @ 73°F (10.3 bar @ 23°C)
Operating
Temperature
+32°F to +140°F (0°C to +60°C) - Do not allow uid to freeze inside meter
Storage
Temperature
-40°F to +140°F (-40°C to +60°C)
Field
Calibration
Yes
Wetted
Components
Housing: PVC | Journal bearings: Ceramic | Shaft: Tungsten carbide
Rotor and supports: PVDF | Retaining washer: Stainless steel
Inlet / Outlet Connections
TM05 TM07 TM10 TM15 TM20
S - (SPIGOT) 1/2 inch Schd. 80 3/4 inch Schd. 80 1 inch Schd. 80
1-1/2 inch
Schd. 80
2 inch Schd. 80
N - (NPT) 1/2 inch NPT 3/4 inch NPT 1 inch NPT 1-1/2 inch NPT 2 inch NPT
B - (BSP) N/A N/A 1 inch BSP 1-1/2 inch BSP 2 inch BSP
Weight
S - (SPIGOT)
0.38 lbs.
(0.172kg)
0.43 lbs.
(0.195kg)
0.49 lbs.
(0.222kg)
0.66 lbs.
(0.299kg)
0.78 lbs.
(0.354kg)
N - (NPT)
0.55 lbs.
(0.249kg)
0.67 lbs.
(0.304kg)
0.84 lbs.
(0.381kg)
1.38 lbs.
(0.628kg)
1.78 lbs.
(0.807kg)
B - (BSP) N/A N/A
0.84 lbs.
(0.381kg)
1.47 lbs.
(0.666kg)
1.93 lbs.
(0.875kg)
Weight shown is with computer display. Output modules add 0.30 lbs/0.14 kg

Flomec TM Series Specifications
