XII. Lubrication Guide
(Excerpt from: GEK-72836E)
Table 5: Motor Lubrication Guide
Type of
Service
Typical Examples
HP Range
Lubrication Interval (Yrs.)
Horizontal
Vertical
Easy
Valves, door openers, portable floor
sanders, motor operating
infrequently (one hour per day)
1 – 7.5
10 – 40
50 – 150
200 – 350
400 - 1000
10
7
4
3
1
9
3
1.5
9 months
---
Standard
Machine tools, air-conditioning
apparatus, conveyors (one or two
shafts), garage compressors,
refrigeration machinery, laundry
machinery, oil well pumps, water
pumps, woodworking machinery
1 – 7.5
10 – 40
50 – 150
200 – 350
400 - 1000
7
4
1.5
1
6 months
3
1
6 months
3 months
---
Severe
Motor for fans, MG- sets, etc., that
run 24 hours per day, 365 days per
year; coal and mining machinery;
motors subject to severe vibration;
steel mill machinery
1 – 7.5
10 – 40
50 – 150
200 – 350
400 - 1000
4
1.5
9 months
6 months
3 months
1.5
6 months
3 months
1.5 months
---
Very
Severe
Dirty, vibrating applications; where
end of shaft is hot (pumps and fans);
high ambient temperature
1 – 7.5
10 – 40
50 – 150
200 – 350
400 - 1000
9 months
4 months
4 months
3 months
2 months
6 months
3 months
2 months
1 month
---
Table 6: Number of Grease Gun Pumps
Bearing Size on
Motor Nameplate
Number of Pumps
Bearing Size on
Motor Nameplate
Number of Pumps
16 Oz. Gun
(Approx. 475
mL)
24 Oz. Gun
(Approx. 700 mL)
16 Oz. Gun
(Approx. 475
mL)
24 Oz. Gun
(Approx. 700
mL)
6205
5
3
6312
40
27
6206
6
4
6314
50
35
6208
10
7
6315; C 2315
65
45
6210
25
17
6316
60
40
6213
35
23
6318; NU 318
75
50
6220
58
39
6320; NU 320; C
2320
95
65
6309
20
13
6321
153
102
6310
25
17
6324; NU324
246
164
NOTE: A standard 10,000 PSI (69 kPa) 16 ounce (475 mL) grease gun delivers approximately 0.04 oz. (1.18
mL) of grease with each pump, and a 24 oz. (710 mL) gun delivers approximately 0.06 oz. (1.77 mL) of
grease. The number of pumps listed represents approximately 20% of the total grease cavity volume in
end shield.
