Flowserve Limitorque B320 series - Table 6.2- Common Parts List

19
Limitorque B320 Series FCD LMENIM3201-02 – 01/15
flowserve.com
Table 6.2– Common Parts List
Piece Quantity Description
1 1 Housing
2 1 Base
3 1 Bevel Gear
4 1 Stem Nut
5 1 Thrust Ring
6 2 Needle Bearing
7 4 Thrust Washer
8 A/R Ball Bearings
9 1 O-ring
10 1 O-ring
11 1 O-ring
12 A/R Lockwasher
13 A/R Hex Head Cap Screw
14 1 Grease Fitting
15 1 Plain Washer
16 1 Flat Head Mach. Screw
17 1 Nameplate
18 2 Drive Screw
19 1 Grease Fitting Cap
20 1 Endcover
21 1 Bevel Pinion
22 (B320-20) 2 Spacer
23 (B320-20) 2 Ball Bearing
22 (B320-40) 2 Spacer
23 (B320-40) 3 Ball Bearing
22 (B320-50) 2 Spacer
23 (B320-50) 2 Ball Bearing
22 (B320-70) 1 Spacer
22A (B320-70) 1 Spacer
23 (B320-70) 2 Spacer
22 (B320-80) 1 Spacer
23 (B320-80) 2 Ball Bearing
23A (B320-80) 1 Ball Bearing
24 1 O-ring
25 A/R Shim
26 1 Key
27 4 Lockwasher
28 4 Hex Head Cap Screw
29 1 Circlip
43 (B320-80) 1 Washer
52 1 Motorized Adapter
53 1 Lockwasher
54 1 Hex Head Cap Screw
56 (B320-50) 1 Spacer Ring (not shown)
61 (B320-20, -40, -50, -70) 1 O-ring
Note: A/R–as required
