Limitorque B320 Series FCD LMENIM3201-02 – 01/15
flowserve.com
2.2 Product Identification
Figure 2.1 – B320 Bevel Gear Operator
2.3 Inspection and Recording
Upon receipt of the gear operator, inspect the condition of the equipment and record nameplate
information.
1. Carefully remove gear operator from shipping carton or skid. Thoroughly examine the equipment
for any physical damage that may have occurred during shipment. If damaged, immediately
report the damage to the transport company.
2. A nameplate is attached to each gear operator with the following information:
• Operator Size
• Limitorque Order Number
• Ratio
• Serial Number
Record this information for future reference, for ordering parts or obtaining further information.
Input Shaft Mounting Base Housing
Nameplate
