Flowserve Limitorque B320 series - Table 6.7 - 17.5:1 SGA Parts List for B320-90

29
Limitorque B320 Series FCD LMENIM3201-02 – 01/15
flowserve.com
Table 6.7 – 17.5:1 SGA Parts List for B320-90
Piece Quantity Description
200 1 Housing
201 1 Housing Cover
202 1 1st Set Input Shaft/Pinion
203 1 1st Set Output Gear
204 1 2nd Set Input Shaft
205 1 2nd Set Input Gear
206 1 2nd Set Output Gear
207 1 Spacer
208 1 Bushing
209 3 Bushing
210 2 Thrust Washer
211 1 Quad Ring
212 1 O-ring
213 1 Gasket
214 2 Expansion Plug
215 1 Expansion Plug
216 1 Flatwasher
217 1 Lockwasher
218 1 Socket Head Cap Screw
219 2 Dowel Pin
220 8 Socket Head Cap Screw
221 8 Lockwasher
222 6 Hex Head Cap Screw
223 6 Lockwasher
347 1 Pipe Plug (not shown)
