Table 2
Electrical Specifications
Power supply Two-wire, 4-20 mA input
Compliance voltage 10 VDC @ 20 mA
Effective resistance 500 Ω @ 20 mA
Communications HART Protocol
Minimum required
start-up current
3.6 mA
Minimum operating current 3.6 mA
Table 3
SoftTools Requirements
Computer
A computer using a Pentium, higher,
or compatible processor and running
Windows 95, 98, NT, 2000, or XP
Drive CD-ROM drive
Memory
32MB RAM minimum
(64MB RAM recommended)
Hard Drive
Approximately 30MB disk space for
installation
Ports
1 minimum available with 8 maximum
possible. (Can also communicate via
PCMCIA and USB connections)
Modem
HART Compatible RS-232 / PCMCIA /
USB Modem
Table 4
Physical Specifications
Operating
temperature range
Standard: -4°F to 176°F (-20°C to
80°C)
Low: -40°F to 176°F (-40°C to 80°C)
Housing
Cast, powder-painted aluminum
or stainless steel
Weight
Aluminum: 8.5 lb. (3.9 kg)
Stainless steel: 20.5 lb. (9.3 kg)
Table 5
Performance Specifications
Response level ≤0.1% full scale
Deadband ≤0.1% full scale
Resolution ≤0.1% full scale
Linearity ±0.5% full scale
Repeatability ≤0.25% full scale
Hysteresis ≤0.5% full scale
Air consumption at 60 psig
(4 barg)
≤0.35 SCFM
(0.5 Nm
3
/hr)
Max./min. air supply 150 psig/30 psig (10.3 barg/2 barg)
Table 6
Hazardous Area Certifications
FM/CSA
Intrinsically Safe Explosion Proof
Class I, Div 1, Groups A, B, C, D
Class II, Div 1, Groups E, F, G
(See Figure 1 for installation requirements.)
Class I, Div 1,
Groups B, C, D
Class II, Div 1,
Groups E, F, G
NEMA /Type 4x
ATEX (CENELEC)
Intrinsically Safe
II 1G EEx ia IIC T4, T5
T4 Ta = -40°C to 80°C
T5 Ta = -40°C to 35°C
IP-65
Flameproof
II 2 GD EEx d IIB + H
2
T5, Ta = -40°C to 80°C
IP-65
Compliant
IECEx
Flameproof
Ex d IIB + H
2
T5 Ta = -20°C to 55°C
IP-65
Specifications
