Logix 3200IQ Digital Positioner FCD LGENTB0059-03 – 01/11
4
Table 1
Features Advantages
Easy commissioning
Commissioning is performed by simply setting a few switches and pressing the QUICK-CAL button. The Direct User
Interface allows local access to positioner control without requiring multi-level menus, a handheld communicator
or laptop computer.
Local status LEDs LEDs, visible from a distance, indicate positioner’s current status without removing the cover.
Internal diagnostic codes
LEDs provide instant information relating to internal diagnostic codes. These codes indicate to the user positioner
status and alarms without the need for a handheld communicator or laptop computer.
Fast and simple configura-
tion
With its unique Direct User Interface, the Logix 3200IQ positioner provides fast and easy configuration. Local
configuration switches allow the user to set all basic parameters for positioner operation, such as output charac-
teristic (equal percent, linear or custom), air action, signal direction, gain, tuning, etc.
Jog calibrate
The jog calibrate function allows the user to easily and quickly calibrate the positioner on all actuators without
physical stroke stops. These buttons also allow the user to exercise local (manual) control of the valve.
Auto Tune
A simple press of a button starts the self-calibration and auto tune process, speeding up the commissioning
procedure and ensuring consistency between one valve and the next (regardless of who performs the procedure).
Additionally, a gain selector allows the user to modify the calculated Auto Tune result.
HART communication
Using industry standard HART protocol, the Logix 3200IQ positioner can use existing handheld communicators
and supply extensive information to maintenance database software packages.
Low air consumption
State-of-the-art piezo technology combined with inner-loop feedback produces high-performance control with
minimal air consumption.
21-point characterization
With SoftTools software or a handheld communicator, a custom 21-point characterization curve can be generated
that can be used to change the response of the positioner to meet the process requirements.
Two-stage control design Positioner uses two-stage control to provide faster response and tighter control.
High-friction algorithm Improves control of high-friction ball and globe valves by eliminating overshoot and hunting.
Configuration lockout
Local configuration lockout switch permits users to perform automatic quick-calibration procedures without
modifying existing configuration and tuning settings.
NAMUR and VDI/VDE
mounting kits
NAMUR and VDI/VDE mounting interfaces provides direct standardized mounting to various linear or rotary actua-
tors. Brackets are available for non-NAMUR actuators.
Compact and lightweight The positioner’s compact design allows it to be installed on smaller actuators.
4-20 mA feedback option Modular design allows reliable position feedback without the need for isolators.
Features and Advantages
