Flowserve Logix 3800zb User Manual

Logix™ 3800zb Digital Positioner FCD AIIOM001030_EN 02/23
flowserve.com 41
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
A
B
C
D
E
F
G
17.2 Warnings and Special Conditions for Safe Use
Warning!
• DO NOT OPEN, MAINTAIN OR SERVICE IN AN AREA WHERE AN EXPLOSIVE ATMOSPHERE MAY BE PRESENT
Special Conditions for Safe Use:
• Use appropriately rated cable insulation at higher temperatures.
• Contact Flowserve for Flame Path information.
• The Model 38X0 and 38X1 Positioner enclosures contain aluminum and are considered to present a potential risk of
ignition by impact or friction. Care must be taken into account during installation and use to prevent impact or friction.
Clean only with damp cloth.
• Provisions shall be made externally to provide transient overvoltage protection to a level not to exceed 140% of the peak
rated input voltage.
• Using the box provided on the nameplate, the User shall permanently mark the type of protection chosen for the specific
installation. Once the type of protection has been marked it shall not be changed.
• Potential electrostatic charging hazard. Clean only with a damp cloth.
• Discontinue use of equipment if the fasteners securing the enclosure cover or the cover window are damaged. Contact
Flowserve for repair.
• Cable, cable guard, or conductors in conduit should have insulation rated for at least 18K above the maximum expected
ambient temperature of the environment or installation.
AVERTISSEMENT:
• La substitution de composants peut compromettre la sécurité intrinsèque.
• NE PAS OVRIR, MAINTENIR OU SERVIR DANS UNE ZONE OU UNE ATMOSPHÈRE EXPLOSIVE PEUT ÈTRE PRÈSENTE
Assessed to the following US standards:
FM Class 3600:2011, FM Class 3610:2015, FM Class 3611:2016, FM Class 3615:2006, FM Class 3616:2011, FM Class 3810:2005, ANSI/ISA-12.12.01-2016,
ANSI/ISA 60079-0:2013, ANSI/UL 60079-1:2015, ANSI/ISA 60079-11:2014, ANSI/ISA 60079-15:2012, ANSI/ISA-60079-31: 2015, ANSI/ISA 61010-1:2004, ANSI/UL 50E:2015, ANSI/IEC
60529:2014
Assessed to the following CSA standards:
CSA C22.2 NO. 0.4-04:2017, CSA C22.2 NO. 0.5-16:2016,
CSA C22.2 No. 25-1966:1966 (Reaffirmed 2014), CSA C22.2 No.30-M1986:1986 (Reaffirmed 2016), CSA C22.2 No.94.2:2015, CSA C22.2 No. 213-16:2016, CSA C22.2 No. 1010.1:2004,
CAN/CSA C22.2 No. 60079-0:2015, CAN/CSA C22.2 No. 60079-1:2016,
CAN/CSAC22.2 No. 60079-11:2014, CAN/CSAC22.2 No. 60079-15:2016,
CAN/CSA-C22.2 No. 60079-31:2015, CSA C22.2. 60529:2005 (Reaffirmed 2015)
Assessed to the following EMC standards (EMC Directive 2014/30/EU/EC):
EN 61000-3-2 IEC 61000-4-3 IEC 61000-4-6
EN 61000-3-3 IEC 61000-4-4 IEC 61000-4-8
IEC 61000-4-2 IEC 61000-4-5 IEC 61000-4-11
EN 61326-1:2006 – for use in industrial environments EN 61326-1:2013
EN 55011 Class A Group 1
Namur NE 21 Version: 22.08.2007
