Logix
®
520MD+ and 510+ Digital Positioners FCD LGENIM0105-15-AQ – 05/16
80
21.2 Spare Parts Kits
Table 29: Spare Parts Kits
Ref. Description Part-no.
Cover:
1 Yellow 283450.999.000
1 Black 283451.999.000
1 White 283452.999.000
Board:
2 505+ Main 331625.999.000
520MD+ Main 283453.999.000
5 LCD 283454.999.000
6 Pressure Sensor 283455.999.000
7 Multi-Function Card (Slot1) 283456.999.000
Multi-Function Card (Slot2) 314887.999.000
8 V to I Card (Slot 1) 331725.999.000
Pilot Relay Module:
10 Single Acting (Poppet) 283458.999.000
11 Double or Single Acting (Spool) 283459.999.000
12 Pneumatic Restrictor 291750.999.000
Limit Switches:
13 Mechanical Switch* 291751.999.000
14 Reed Switch 291752.999.000
15 P&F SJ2-SN** 291753.999.000
16 P&F SJ2-S1N** 291754.999.000
17 P&F NJ2-V3-N** 291755.999.000
18 P&F NBB2-V3-2N* 291755.999.000
* Only available for general purpose (certification option 14).
** Only available for certification options 14 and 42.
NOTE: Multi-function cards and limit switches may be purchased
as upgrades and installed after the initial purchase of the
positioner. In this case, the positioner label must be modified
to reflect the change.
