USER INSTRUCTIONS MARK 3 High Silicon Iron ENGLISH 71569249 09-04
®
The pump may be stored as above for up to 6
months. Consult Flowserve for preservative actions
when a longer storage period is needed.
2.4.1 Short term storage and packaging
Normal packaging is designed to protect the pump
and parts during shipment and for dry, indoor storage
for up to six months or less. The following is an
overview of our normal packaging:
• All loose unmounted items are packaged in a
water proof plastic bag and placed under the
coupling guard
• Inner surfaces of the bearing housing, shaft (area
through bearing housing) and bearings are coated
with Cortec VCI-329 rust inhibitor, or equal.
Bearing housings are not filled with oil
prior to shipment
• Regreasable bearings are packed with grease
(EXXON POLYREX EM for horizontal pumps)
• The internal surfaces of ferrous casings, covers,
flange faces, and the impeller surface are
sprayed with Cortec VCI-389, or equal
• Exposed shafts are taped with Polywrap
• Flange covers are secured to both the suction
and discharge flanges
• In some cases with assemblies ordered with
external piping, components may be
disassembled for shipment
• The pump must be stored in a covered, dry
location
2.4.2 Long term storage and packaging
Long term storage is defined as more than six
months, but less than 12 months. The procedure
Flowserve follows for long term storage of pumps is
given below. These procedures are in addition to the
short term procedure.
• Each assembly is hermetically (heat) sealed from
the atmosphere by means of tack wrap sheeting
and rubber bushings (mounting holes)
• Desiccant bags are placed inside the tack
wrapped packaging
• A solid wood box is used to cover the assembly
This packaging will provide protection for up to twelve
months from humidity, salt laden air, dust etc.
After unpacking, protection will be the responsibility of
the user. Addition of oil to the bearing housing will
remove the inhibitor. If units are to be idle for extended
periods after addition of lubricants, inhibitor oils and
greases should be used. Every three months, the pump
shaft should be rotated approximately 10 revolutions.
2.5 Recycling and end of product life
At the end of the service life of the product or its
parts, the relevant materials and parts should be
recycled or disposed of using an environmentally
acceptable method and in accordance with local
regulations. If the product contains substances that
are harmful to the environment, these should be
removed and disposed of in accordance with current
local regulations. This also includes the liquids
and/or gases that may be used in the "seal system"
or other utilities.
Make sure that hazardous substances are
disposed of safely and that the correct personal
protective equipment is used. The safety
specifications must be in accordance with the current
local regulations at all times.
3 DESCRIPTION
3.1 Configurations
The Durco Mark 3 chemical process pumps are,
single stage, centrifugal pumps. The High Silicon
Iron pump conforms dimensionally to ASME B73.1M.
The pump does not have cast on flanges and does
not offer back pull out.
Figure 3-1: Nameplate mounted to housing
2K3X1.5 H-10/9.5 OP
Serial No.
Equipment No.
Purchase Order
Model
Size
MDP
Material
Date DD/MMM/YY
Page 10 of 48
