USER INSTRUCTIONS MARK 3 High Silicon Iron ENGLISH 71569249 09-04
®
Item No. Part Description Item No. Part Description
1100 Casing 4310.1 Oil Seal – Inboard
1223 Suction Cover 4310.2 Oil Seal – Outboard
1240 Clamping Ring 4590.1 Gasket – Cover
1245.1 Flange – Split 4590.2 Gasket – Impeller
1245.2 Flange – Split 4590.3 Gasket – Seat to Gland
1340 Bearing Adapter 4590.4 Gasket – Gland
2100 Shaft 4590.5 Gasket Spacer
2200 Impeller 4610.1 O-ring – Adapter to Bearing Housing
2400 Sleeve – Shaft (optional) 4610.2 O-ring – Bearing Carrier
2530.1 Retainer – Snap Ring 6521 Vent / Plug
2530.2 Retainer – Duplex Bearing 6541.1 Lockwasher – Bearing
2540 Deflector 6541.2 Lockwasher – Spit Gland
2541 Slinger (optional) 6569 Plug – Housing Drain
3011 Bearing – Inboard 6570.1 Fastener – Casing
3013 Bearing – Outboard 6570.2 Fastener – Bearing Retainer
3126.1 Shim – Rear Foot 6570.3 Fastener – Carrier Setscrews
3134 Foot – Bearing Housing 6570.4 Fastener – Foot
3200 Bearing Housing 6570.5 Fastener – Bearing Housing to Adapter
3240 Bearing Carrier 6570.6 Fastener – Gland
3712 Locknut - Bearing 6570.7 Fastener – Spit Gland
3855 Oiler (optional) 6580.1 Hexnut – Casing
3856 Sight Gage – Bearing Housing 6580.2 Hexnut- Gland
4120 Gland 6580.3 Hexnut – Split Gland
4121.1 Split Gland Yoke – Tapped 6700 Key – Drive Shaft
4121.2 Split Gland Yoke – Un-tapped
4130 Packing
