EP5 Electro Pneumatic Digital Positioner FCD PMENIM0006-00-A5 12/18
28
No Part no Qty Description Remarks
1. 1 Housing 1 N/A
2. P4-xx 1 Front cover
3. P4-7 1 Diaphragm cover incl. O-ring
4. P5-8 1 Diaphragm
5. P5-9 2 Diaphragm washer
6. P5-10 1 Balance arm
7. P5-AS13/315 1 Feedback spring 3-15 Psi assembly
7. P5-AS13/630 1 Feedback spring 6-30 Psi assembly (Green)
8. P4-AS18 1 Lower arm assembly
9. P5-19 1 Rod
10. P5-20 1 Spring
11. P5-24 1 Twist stop
12. P4-AS25 1 Pilot valve incl. O-rings
13. P5-27 1 Cam locking nut incl. screw
15. P5-31 1 Mounting adapter incl. screws
16 P5-32 1 Ball bearing
17. P5-K1 1 Cam K1 90°/180° Linear 0-100%,
split range 0-50-100% 1
17. P5-Kxx 1 Cam special, K2-K10 (ConsultPMV)
18. P4- 1 Cxx Spindle (Consult PMV)
19. 12013 1 Indicator Arrow type 1
20. P4-SCREW Screw set Set
21. P4-SEAL NBR Seal and O-ring set NBR, Nitrile rubber. Set (4, 21)
