E110-SERIES TUTORIAL AUTOMATIC UNIT CONVERSION
FW_E110_AutoUnitConv_002_EN Page 7
2.1.2 The automatic unit conversion - HAND mode
This procedure gives the information how to setup the HAND mode. The HAND mode is
selected when the required measurement unit is not supported by the automatic unit
conversion.
ACTION
RESULT
NOTICE
1. Press the PROG button
for at least 7 seconds.
 The SETUP indicator
comes on continuously.
-
2. Wait for the setup menu
to show.
 The setup menu shows.
-
3. Press the ► button until
the FLOWMETER
menu shows.
 The FLOWMETER menu
shows.
In this menu you can match the
flowmeter with the E-series.
4. Press the ▲ button until
the UNITS menu
shows.
 The UNITS menu shows.
The UNITS menu is used to make
a choice between the automatic
unit conversion modes.
5. Press the PROG button
momentarily.
 The PROG indicator
comes on.
For measurement units which are
not supported, select HAND.
6. Press the ▲ button to
make the required
selection.
 The HAND selection
shows.
For the explanation,
the mode HAND is selected.
7. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
8. Press the ▲ button to
make the required
selection.
 The FLOWMETER menu
shows.
2.2 Set the reading for the (accumulated) total
This chapter explains the procedure how to setup the measurement unit for reading the
E-series.
2.2.1 The (accumulated) total - AUTO-VOL and AUTO MAS mode
This setting does not influence the K-Factor measurement unit as set from the flowmeter
certificate. The displayed measurement unit, as you selected, for the (accumulated) total is
calculated from the settings in the flowmeter menu.
NOTICE
This procedure is only applicable for the automatic unit conversion modes
AUTO-VOL and AUTO-MASS.
ACTION
RESULT
NOTICE
1. Press the ► button
until the TOTAL menu
shows.
 The TOTAL menu shows
Now you can set the TOTAL
settings, but not the K-Factor Factor
(decimals) because these settings
are controlled by the FLOWMETER
settings.
2. Press the ▲ button until
the UNIT menu shows.
 The UNIT menu shows.
-
3. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the measurement
unit for display purpose only. The
automatic unit conversion takes
care for the correct reading with
respect to the flowmeter calibration.
