Fluidwell E018 Tutorial

E110-SERIES TUTORIAL AUTOMATIC UNIT CONVERSION
FW_E110_AutoUnitConv_002_EN Page 9
2.2.2 The (accumulated) total - HAND mode
This procedure gives the information how to setup the HAND mode. The HAND mode is
selected when the required measurement unit is not supported by the automatic unit
conversion.
NOTICE
This procedure is applicable for the HAND mode where the K-Factor for the
(accumulated) total is set by hand. For the explanation, US GAL is the selected
measurement unit for the (accumulated) total.
ACTION
RESULT
NOTICE
1. Press the PROG button
until the TOTAL menu
shows.
 The TOTAL menu shows.
In this menu you can setup the
reading for the (accumulated) total.
2. Press the ▲ button until
the UNIT menu shows.
 the UNIT menu shows.
-
3. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the measurement
unit for the (accumulated) total.
A change of the measurement unit
requires also a new calculation of
the K-Factor for the (accumulated)
total. The calculation is not done
automatically!
4. Press the ▲ button to
make the required
selection.
 The selection US GAL
shows.
For the explanation,
the measurement unit for the
(accumulated) total are set to
US GAL.
5. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
6. Press the ▲ button until
the DECIMALS menu
shows.
 The DECIMALS menu
shows.
-
7. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the decimal
pointer for display purposes only.
8. Press the ▲ button to
make the required
selection.
 The selection 0 shows.
For the explanation,
the decimals for the (accumulated)
total are set to 0 decimals.
9. Press the PROG button
momentarily.
 The PROG indicator goes
off.
 The selection is
confirmed.
-
10. Press the ▲ button until
the K-FACTOR menu
shows.
 The K-FACTOR menu
shows.
Calculate the K-Factor for the
(accumulated) total by hand and
make a note.
11. Press the PROG button
momentarily.
 The PROG indicator
comes on.
Now you can set the calculated
K-Factor for the (accumulated)
total.
12. Use the ▲ button and
the ► button to enter
the required data.
 The K-FACTOR menu
shows 25.077.
For the explanation,
the K-Factor 6624.605 with an unit
m
3
converted into US GAL gives
6624.605 : 264.17 = 25.077.
