HF012PEN_v0402_03 Atex_IECEx_CSA_FM
Page 32
5.4. BATTERY REPLACEMENT INSTRUCTIONS
Manufacturer
Battery label:
Mounting, electrical installation, start-up and maintenance of
this device may only be carried out by trained personnel
authorized by the operator of the facility.
Personnel must read and understand this Instruction before
carrying out its instructions.
unplug the connector carefully and lift
It is allowed to replace the Intrinsically Safe battery FW-LiBAT-001
in hazardous area. The battery may only be replaced with an
original
the old
battery out of the mounting clip. The new battery can be placed in
the clip and the connector plugged on the board.
FW-LiBAT-001 manufactured by Fluidwell bv.
For replacement,
WARNING: Fire, explosion or severe burns may result if
mistreated. Do not recharge, crush, disassemble, incinerate,
heat above 100°C (212°F) or expose contents to water.
INSTRUCTION SHEET BATTERY REPLACEMENT FW-LiBAT-001
Replacement Instructions
Safety Instructions
Fluidwell bv - The Netherlands
www.fluidwell.com - sales@fluidwell.com
FW-LiBAT-001 - INST001
Primary Lithium Battery - Only replace with Fluidwell I.S. battery pack !
II 1 G Ex ia IIC
Ga Ex ia IIC
KEMA 03ATEX1071 U
IECEx KEM 08.0005U
0344
Fluidwell bv - Intrinsically Safe Battery
Part. no.: FW-LiBAT-001
Uo = 3.9V Co = 100 F
Io = 35mA Lo = 25mH
Po = 35mW Ta = -40°C to +70°C
µ
Consult manual for replacement instructions.
WARNING: Fire, explosion or severe
may result if mistreated. Do not
crush, disassemble, incinerate, heat
100°C (212°F) or expose contents to water.
burns
recharge,
above
WARNING
Disposal
Disposal should be done in accordance with applicable regulations,
which vary from country to country. Trashing of used batteries is
forbidden and disposal can be done through non-profit organizations
mandated by local authorities or organized by professionals.
B
A
T
T
E
R
Y
F0-series:
Fig. 18: Battery replacement instructions Intrinsically Safe Battery.
