HF012PEN_v0402_03 Atex_IECEx_CSA_FM
Page 34
APPENDIX A: TECHNICAL SPECIFICATION
Display
Type High intensity reflective numeric and alphanumeric LCD, UV-resistant.
Digits Seven 17mm (0.67") and eleven 8mm (0.31"). Various symbols and measuring units.
Refresh rate User definable: 8 times/sec - 30 secs.
Type ZB (option) Bi-color configurable LED-backlight - green or amber. Intensity adjustable from the keyboard.
Enclosures
General
Control Keys
Painting
Die-cast aluminum or GRP (Glassfibre Reinforced Polyamide) enclosure with Polycarbonate
window, silicone and EPDM gaskets. UV stabilized and flame retardant material.
Three industrial micro-switch keys. UV-resistant silicone keypad.
Aluminum enclosure only: UV-resistant 2-component industrial painting.
Panel-mount enclosures
Classification
Panel cut-out
Type HC
Type HB
Dimensions: 130 x 120 x 60mm (5.10" x 4.72" x 2.38") – LxHxD.
IP65 / NEMA 4X
115 x 98mm (4.53" x 3.86") LxH.
GRP panel-mount enclosure
Aluminum panel-mount enclosure
Field/wall-mount enclosures
Classification
Aluminum enclosures
Type HA
Type HM
Type HN
Type HO
Type HP
Type HT
Type HU
Type HV
Type HZ
GRP enclosures
Type HD
Type HE
Type HF
Type HG
Type HJ
Type HH
Type HK
ABS enclosure
Type HS
Dimensions: 130 x 120 x 75mm (5.10” x 4.72” x 2.95”) – LxHxD.
IP67 / NEMA4X
Drilling: 2x PG9 – 1x M20.
Drilling: 2x M16 – 1x M20.
Drilling: 1x M20.
Drilling: 2x M20.
Drilling: 6x M12.
Drilling: 1x ½”NPT.
Drilling: 3x ½”NPT.
Drilling: 4x M20
No drilling.
No drilling.
Drilling: 2x 16mm (0.63”) – 1x 20mm (0.78”).
Drilling: 1x 22mm (0.87”).
Drilling: 2x 20mm (0.78”).
Drilling: 3x 22mm (0.87”).
Drilling: 6x 12mm (0.47”).
Flat bottom - no drilling.
Silicone free ABS enclosure with EPDM and PE gaskets. UV-resistant polyester keypad.
(no drilling)
Operating temperature
Operational -40°C to +80°C (-40°F to +178°F).
Intrinsically Safe -40°C to +70°C (-40°F to +158°F).
Power requirements
Type PB Lithium battery - life-time depends upon settings - up to 5 years.
Type PC Intrinsically Safe lithium battery - life-time depends upon settings - up to 5 years.
Type PD 16-30 V DC. Power consumption max. 1 Watt.
Type PF 24V AC/DC +10%. Power consumption max. 15 Watt.
Type PL Input loop powered from 4-20mA signal input. Voltage drop max. 2.6V DC
Type PM 115-230V AC +10%. Power consumption max. 15 Watt.
Type PX 8-30 V DC (also available with PB / PC). Power consumption max. 0.3 Watt.
Type ZB 20-30V DC. Power consumption max. 1 Watt. Note: with type PF / PM: internally powered.
Note PF / PM The total consumption of the sensor and backlight type ZB may not exceed 400mA@24V DC.
Note I.S. application for intrinsically safe applications, consult the safety values in the certificate.
