HF110PEN_v0501_04
Page 42
Analog output
Function transmitting flowrate.
Accuracy 10 bit. Error < 0.05% - update 10 times a second.
Software function to calibrate the 4.00mA and 20.00mA levels precisely within set-up.
Load max. 1 kOhm
Type AA Active 4-20mA output (requires type OA + PD, PF or PM).
Type AB Active 0-20mA output (requires type OA + PD, PF or PM).
Type AF Passive floating 4-20mA output for Intrinsically Safe applications (requires PC or PD).
Type AI Passive galvanically isolated output (requires PB, PD, PF, PL or PM).
Type AP Passive 4-20mA output - output loop powered (type PX).
Type AU Active 0-10V output (requires type OA + PD, PF or PM).
Switch output(s)
Function One pulse output - transmitting accumulated total.
Pulse output Max. frequency 60Hz. Pulse length user definable between 7,8msec up to 2 seconds.
Type OA Active 24V DC transistor output; max. 50mA per output (requires type AA + PD, PF or PM).
Type OR Isolated mechanic relay output; max. switch power 230V AC - 0,5A (requires type PF or PM).
Type OT Passive transistor output - not isolated. Load max. 50V DC - 300mA.
Communication option
Functions reading display information, reading / writing all settings.
Protocol Modbus ASCII or RTU
Speed 1200 - 2400 - 4800 - 9600 baud
Addressing maximum 255 addresses.
Type CB RS232
Type CH RS485 2-wire
Type CI RS485 4-wire
Type CT TTL Intrinsically Safe communication.
Type CX no communication.
Operator functions
Displayed functions
• total and/or flowrate.
• total and accumulated total.
• total can be reset to zero by pressing the CLEAR-key twice.
Total
Digits 7 digits.
Units L, m3, GAL, USGAL, KG, lb, bbl, no unit.
Decimals 0 - 1 - 2 or 3.
Note total can be reset to zero.
Accumulated total
Digits 11 digits.
Units / decimals according to selection for total.
Flowrate
Digits 7 digits.
Units mL, L, m3, Gallons, KG, Ton, lb, bl, cf, RND, ft3, scf, Nm3, Nl, igal - no units.
Decimals 0 - 1 - 2 or 3.
Time units /sec - /min - /hr - /day.
OUTPUTS
OPERATIONAL
