APPENDIX C: COMMUNICATION VARIABLES
Remarks:
 Below, an overview of the F110-P specific variables; other common variables are described in
the standard table.
 All numbers are decimal numbers, unless otherwise noted.
 The following variables of the standard table (var00-var30) are not valid for this product and will
be responded with value 1: var00, 03-05, 07,08, 16-22, 24, 26-29.
CONFIGURATION VARIABLES F110-P - SETUP-LEVEL:
VAR DESCRIPTION BYTES VALUE REMARKS
TOTAL
32
(20h)
unit 1 0=L
1=m3
2=kg
3=lb
4=gal
5=usgal
6=bbl
7=none
33
(21h)
decimals 1 0…3
34
(22h)
K-factor 3 1....9.999.999 K-f 0000001 - K-f 0000009 is
allowed when decs < 6! (VAR37)
37
(25h)
decimals K-factor 1 0…6
FLOWRATE
48
(30h)
unit 1 0=mL
1=L
2=m3
3=mg
4=g
5=kg
6=ton
7=gal
8=bbl
9=lb
10=cf
11=rev
(revolutions for
RPM)
12=none
13=scf
14=NM3
15=NL
16=p
49
(31h)
time unit 1 0=sec
1=min
2=hour
3=day
50
(32h)
decimals 1 0…3
51
(33h)
K-factor 3 1....9.999.999 K-f 0000001 - K-f 0000009 is
allowed when decs < 6! (VAR54)
54
(36h)
decimals K-factor 1 0…6
55
(37h)
number of pulses 1 1..255
56
(38h)
cut-off time 2 1 .. 9999 steps of 100ms
