Fluidwell F110-P - Configuration Variables Summary; Display and Power Management Variables; Flowmeter, Analog, and Pulse Output Variables; Other Configuration Variables (Pass Code, Tag)

HF110PEN_v0501_04
Page 45
VAR DESCRIPTION BYTES VALUE REMARKS
DISPLAY
64
(40h)
display function 1 0=total
1=flowrate
68
(44h)
set flowrate monitor 1 0=operator level
1=SETUP level
POWERMANAGEMENT
80
(50h)
LCD update time 1 0=fast
1=1sec
2=3sec
3=15sec
4=30sec
5=off
81
(51h)
power-mode battery 1 0=operational
1=shelf
FLOWMETER
96
(60h)
flowmeter signal 1 0=npn
1=npn-lp
2=reed
3=reed LP
4=pnp
5=pnp-lp
6=namur
7=coil hi
8=coil lo
ANALOG OUTPUT
112
(70h)
analog output 1 0=disable
1=enable
113
(71h)
minimum rate 3 0..9999999 unit, time, decimals acc. var48-50
116
(74h)
maximum rate 3 0..9999999 unit, time, decimals acc. var48-50
119
(77h)
cut off percentage 1 0..99 steps of 0.1%
120
(78h)
tune minimum rate 2 0..9999
122
(7Ah)
tune maximum rate 2 0..9999
99
(63h)
filter 1 0….99
PULSE OUTPUT
128
(80h)
impulse width 1 0=off
1=short
2=long
129
(81h)
pulse per X quantity 3 1..9999999 unit, decimals acc. var32 -33
OTHERS
168
(A8h)
pass code 2 xxxx read only!
170
AAh
tagnumber 3 0..9999999 Other vars: see standard table
