3.2.2. OVERVIEW FUNCTIONS SETUP LEVEL
SETUP FUNCTIONS AND VARIABLES
1 TOTAL
11 UNIT L - m3 - kg - lb - GAL - USGAL - bbl - no unit
12 DECIMALS 0 - 1 - 2 - 3 (Ref: displayed value)
13 K-FACTOR: 0.000010 - 9,999,999
14 DECIMALS K-FACTOR 0 - 6
2 FLOWRATE
21 UNIT mL - L - m3 - mg - g - kg - ton - GAL - bbl - lb - cf - REV -
no unit - scf - Nm3 - NL - P
22 TIME UNIT sec - min - hour - day
23 DECIMALS 0 - 1 - 2 - 3 (Ref: displayed value)
24 K-FACTOR 0.000010 - 9,999,999
25 DECIMALS K-FACTOR 0 - 6
26 CALCULATION per 1 - 255 pulses
27 CUT-OFF 0.1 - 999.9 seconds
3 DISPLAY
31 FUNCTION total - flowrate
4 POWER MANAGEMENT
41 LCD UPDATE fast - 1 sec - 3 sec - 15 sec - 30 sec - off
42 BATTERY MODE operational - shelf
5 FLOWMETER
51 SIGNAL A npn - npn_lp - reed - reed_lp - pnp - pnp_lp - namur -
coil_hi - coil_lo - act_8.1 - act_12 - act_24
52 SIGNAL B npn - npn_lp - reed - reed_lp - pnp - pnp_lp - namur -
coil_hi - coil_lo - act_8.1 - act_12 - act_24
53 BI-DIRECTIONAL disable - enable
54 PHASE 90° - 270°
55 COUNT NEGATIVE disable - enable
6 ANALOG
61 OUTPUT disable - enable
62 RATE MIN. (0/4mA-0V) 0000.000 - 9,999,999
63 RATE MAX. (20mA - 10V) 0000.000 - 9,999,999
64 RATE NEGATIVE absolute - ignore
65 CUT-OFF 0.0 - 9.9%
66 TUNE MIN - 4mA / 0V 0 - 9,999
67 TUNE MAX- 20mA / 10V 0 - 9,999
68 FILTER 00 - 99
7 IMPULSE
71 PERIOD TIME 0 - 250
72 IMPULSE PER X,XXX,XXX quantity
8 COMMUNICATION
81 SPEED / BAUDRATE 1200 - 2400 - 4800 - 9600
82 ADDRESS 1 - 255
83 MODE RTU - off
9 OTHERS
91 TYPE / MODEL
92 SOFTWARE VERSION
93 SERIAL NO.
94 PASS CODE 0000 - 9999
95 TAGNUMBER 0000000 - 9999999
