Fluke 10 - Measuring Voltage

10 Users Manual
8
Measuring Voltage
1. Insert the test leads in the jacks.
2. To select a voltage function, put the slide-switch in the middle position. (Figure 3.)
Press the [
g ] SELECT button to toggle between dc and ac.
3. Touch the probes to the test points, and read the display.
The meter beeps when OL (overload) is displayed.
