110 PLUS and 115
Users Manual
26
Table 2. Input Characteristics
Function Input Impedance (Nominal)
Common Mode Rejection Ratio
(1 kΩ Unbalanced)
Normal Mode
Rejection
Volts AC >5 MΩ <100 pF >60 dB at dc, 50 or 60 Hz
Volts DC >10 MΩ <100 pF >100 dB at dc, 50 or 60 Hz >60 dB at 50 or 60 Hz
Auto-V LoZ ~3 kΩ <500 pF >60 dB at dc, 50 or 60 Hz
Open Circuit Test Voltage Full Scale Voltage Short Circuit Current
Ohms <2.7 V dc To 6.0 MΩ 40 MΩ <350
μ
A
<0.7 V dc <0.9 V dc
Diode Test <2.7 V dc 2.000 V dc <1.2 mA
