Fluke 1550C Calibration Manual

Insulation Tester
Specifications
19
Specifications
General Specifications
Display 75 mm x 105 mm
Power
12 V lead-acid rechargeable battery.
2.6 Ahr
Charger Input (AC)
85 V to 250 V ac, 50/60 Hz, 20 VA
This Class II (double insulated) instrument is supplied with a Class 1
(grounded) power cord. The protective earth terminal (ground pin) is not
connected internally. The extra pin is for added plug retention only
.
Dimensions (H x W x L)
170 mm x 242 mm x 330 mm
(6.7 in. x 9.5 in. x 13.0 in.)
Weight 3.6 kg (7.94 lbs.)
Temperature (operating) -20
°
C to 50
°
C (-4
°
F to 122
°
F)
Temperature (storage) -20
°
C to 65
°
C (-4
°
F to 149
°
F)
Relative Humidity 80 % to 31
°
C decreasing linearly to 50 % at 50
°
C
Altitude 2000 m
Enclosure Sealing IP40
Input Overload Protection 1000 V ac
Electromagnetic
Compatibility
EN 61326-1, EN 61326-2-2
Certifications   
Safety Compliance
EN 61010-1, EN 61557 Parts 1 and 2
CAT III 1000V, CAT IV 600V
Pollution Degree 2
Test Voltages Number of Tests
250 V 4100
500 V 3600
1 kV 3200
2.5 kV 2500
5 kV 1000
Typical Battery Charge
Capability
Note:
At temperature extremes, the
battery needs to be charged
more frequently.
10 kV 500

Fluke 1550C Specifications

General

Display type	-
Housing color	Grey, Yellow
Maximum voltage	5000 V
AC voltage range	250 - 5000 V
Operating altitude	0 - 2000 m
Overload protection	Yes
Storage temperature (T-T)	-20 - 65 °C
Operating temperature (T-T)	-20 - 50 °C
Operating relative humidity (H-H)	0 - 80 %
International Protection (IP) code	IP40
Battery technology	Sealed Lead Acid (VRLA)
Number of batteries supported	1

Weight and Dimensions

Depth	277 mm
Width	269 mm
Height	160 mm
Weight	3700 g
