Fluke 1625 User Manual

Earth/Ground Tester
Procedure of Measurements
27
CONTROL LOOP
MEASURING LOOP
ON/OFF
POWER ON
Function
SELECT MEASURING
FUNTION WITH
CENTRAL ROTARY
SWITCH
1 X DISPLAY
LIMIT
SET VALUE OR
VOLTAGE
MEASUREMENT
1 X CHANGE 1 X SELECT
QUICK
SWITCHOVER,
SET VALUE
DIGIT/DECIMAL POINT
SPOT SELECTION
1 X CHANGE
INCREASE SELECTED
SPOT (DIGIT/DECIMAL
POINT) BY 1
1 X DISPLAY
DISPLAY, MEASURED VALUE
OR SUPPLEMENTARY VALUE
MEASUREMENT
1 X START
edw009.eps
Figure 6. Operational Modes

Fluke 1625 Specifications

General

Storage Temperature	-20 °C to 60 °C
Testing Methods	3-pole fall-of-potential, 4-pole
Measurement Frequency	128 Hz
Power Supply	6 x 1.5 V AA batteries or optional AC adapter
Safety Rating	CAT II 300 V
Safety Standards	IEC 61010-1
