Specifications
61
General Specifications
Size: 9.2 x 3.9 x 2.5 inches (234 x 100 x 64 mm)
Weight: 2.0 lbs (1 kg)
Input Connectors:
Voltage: 2 shrouded banana jacks (4 mm)
Current Probe: 1 shrouded BNC jack
Battery:
Type: 4 Alkaline “C” Cells ANSI/NEDA-14A, IEC-LR14
(supplied)
Operating Time: 48 hours, typical (continuous, without backlight)
Alternate Battery:
4 NiCad Cells, customer supplied and externally charged. The tester
prevents battery reversal by turning itself off if battery voltage drops below
4.0V dc.
Temperature:
Operating: 0 to 50
°C (32 to 122°F)
Storage: -20 to 60
°C (-4 to 140°F)
Temperature Coefficient:
0.1 x Specified Accuracy per degree C
(0 to 18 degrees C, 28 to 50 degrees C)
