789
Users Manual
16
Table 7. Display
No. Element Meaning
A % (Percentage display)
Shows the mA measured value or output level in %, in a 0-20 mA or 4-20 mA scale
(change scales with power-up option)
B OUTPUT
Lights when mA output (source or simulate) is active
C S
Lights in continuity function
D Y
Lights when dangerous voltage is present
E Q
Lights when relative reading is on
F B
Lights when the battery is low
G q
Lights when the meter is transmitting or receiving over the IR port
H Numerals
Show the input or output value
IK lI
Lights when AutoHold is on
J D
Lights in diode test function
K I
Lights when MIN MAX recording is held
L N MAX MINAVG
MIN MAX recording status indicators:
N - MIN MAX recording is on
MAX - the display is showing the maximum-recorded value
MIN - the display is showing the minimum-recorded value
AVG - the display is showing the average value since starting recording (up to
about 40 hours continuous recording time)
