Fluke 80 Series III Service Information

80 Series III
Service Information
4
Specifications
Accuracy
Accuracy is given for a period of one year after calibration, at 18 °C to 28 °C, with
relative humidity up to 90 % as:
±([% of reading] + [number of least significant digits])
For Model 87 in the 4 ½-digit mode, multiply the number of least significant digits
(counts) by 10. AC conversions are ac-coupled and valid from 5 % to 100 % of range.
Models 85 and 87 are true rms responding. AC crest factor can be up to 3 at full scale, 6
at half scale. For non-sinusoidal wave forms add −(2 % reading + 2 % full scale) typical,
for a crest factor up to 3.
General
Maximum Voltage between any Terminal
and Earth Ground
1000 V rms
WFuse Protection for mA or µA inputs
WFuse Protection for A input
44/100 A, 1000 V FAST Fuse
11 A, 1000 V FAST Fuse
Display Digital: 4000 counts updates 4/sec; (Model 87 also has
19,999 counts in 4½-digit mode, updates 1/sec.).
Analog: updates 40/sec.
Frequency: 19,999 counts, updates 3/sec at >10 Hz. Model
87: 4 x 32 segments (equivalent to 128);
Models 83, 85: 43 segments.
Temperature Operating: -20 °C to +55 °C;
Storage: -40 °C to +60 °C
Altitude Operating: 2000 m; Storage: 10,000 m
Temperature Coefficient 0.05 x (specified accuracy)/ °C (<18 °C or >28 °C)
Electromagnetic Compatibility In an RF field of 1 V/m on all ranges and functions except
capacitance: Models 85 and 87 Total Accuracy = Specified
Accuracy + 2.5 % of range. Model 83 Total Accuracy =
Specified Accuracy + 0.3 % of range. Capacitance not
specified in RF fields. Above 1 V/m is not specified.
Relative Humidity 0 % to 90 % (0 °C to 35 °C);
0 % to 70 % (35 °C to 55 °C)
Battery Type 9 V zinc, NEDA 1604 or 6F22 or 006P
Battery Life 400 hrs typical with alkaline (with backlight off)
Shock Vibration
Per MIL-T-28800 for a Class 2 instrument
Size (H x W x L) 1.25 in x 3.41 in x 7.35 in (3.1 cm x 8.6 cm x 18.6 cm)
Size with Holster and Flex-Stand 2.06 in x 3.86 in x 7.93 in (5.2 cm x 9.8 cm x 20.1 cm)
Weight 12.5 oz (355 g)
Weight with Holster and Flex-Stand 22.0 oz (624 g)
Safety Complies with ANSI/ISA S82.01-1994, CSA 22.2 No. 1010.1:1992
to 1000 V Overvoltage Category III. UL listed to UL3111-1.
Licensed by TÜV to EN61010-1.
