Fluke 80 Series III Service Information

80 Series III
Service Information
22
7. For each input, compare the readings on the Meter display to the display readings for
your Model of Meter.
Table 12. µA Tests
Display Reading
Step DC Current 83 III 85 III 87 III
1
2
350.0 µA
3500 µA
348.2 to 351.8
3484 to 3516
348.9 to 351.1
3491 to 3509
348.9 to 351.1
3491 to 3509
AC Current Frequency 83 III 85 III 87 III
3
4
5
6
350.0 µA
350.0 µA
3500 µA
3500 µA
60 Hz
1.0 kHz
60 Hz
1.0 kHz
345.6 to 354.4
345.6 to 354.4
3456 to 3544
3456 to 3544
346.3 to 353.7
346.3 to 353.7
3463 to 3537
3463 to 3537
346.3 to 353.7
346.3 to 353.7
3463 to 3537
3463 to 3537
Testing the Amp (A) Function
To verify the accuracy in the ampere (A) measurement function, do the following:.
1. If necessary, set the Calibrator output to 0.
2. Connect the Calibrator to the
A and COM inputs of the Meter.
3. Turn the rotary switch to
mA/AC.
The Meter enters the DC amp measurement function.
4. Apply the inputs in steps 1 and 2 in Table 13.
5. For each input, compare the readings on the Meter display to the display readings for
your Model of Meter.
6. Set the calibrator output to 0.
7. Press the blue button on the Meter to toggle to the AC amp measurement function.
8. Apply the inputs in steps 3 through 6 in Table 13.
9. For each input, compare the readings on the Meter display to the display readings for
your Model of Meter.
Table 13. Current Tests
Display Reading
Step DC Current 83 III 85 III 87 III
1
2
3500 mA
10.00A
3482 to 3518
9.94 to 10.06
3489 to 3511
9.96 to 10.04
3489 to 3511
9.96 to 10.04
AC Current Frequency 83 III 85 III 87 III
3
4
5
6
3500 mA
3500 mA
10.00 A
10.00 A
60 Hz
1.0 kHz
60 Hz
1.0 kHz
3456 to 3544
3456 to 3544
9.86 to 10.14
9.86 to 10.14
3463 to 3537
3463 to 3537
9.88 to 10.12
9.88 to 10.12
3463 to 3537
3463 to 3537
9.88 to 10.12
9.88 to 10.12
