Fluke 80 Series III Service Information

Multimeters
Specifications
5
AC Voltage Specifications (Models 85 and 87)
Function Range Resolution Accuracy
1
50-60 Hz 45 Hz - 1 kHz 1-5 kHz 5-20 kHz
2
K
3
400.0 mV
4.000 V
40.00 V
400.0 V
1000 V
0.1 mV
0.001 V
0.01 V
0.1 V
1 V
±(0.7 % + 4)
±(0.7 % + 2)
±(0.7 % + 2)
±(0.7 % + 2)
±(0.7 % + 2)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
5
±(2.0 % + 4)
±(2.0 % + 4)
±(2.0 % + 4)
±(2.0 % + 4)
4
unspecified
±(2.0 % + 20)
±(2.0 % + 20)
±(2.0 % + 20)
unspecified
unspecified
1. For extended use at high RH, change the 400 mV and 4.0 V ac accuracy specification to ± (1.5 % + 4 counts) for 45
Hz to 1 kHz and ± (3.0 % + 25 counts) for 5 kHz to 20 kHz.
2. Below 10 % of range, add 6 counts.
3. Models 85 and 87 are true rms responding Meters. When the input leads are shorted together in the ac functions,
the Meters display a reading (typically <25 counts) caused by internal amplifier noise. The accuracy on Models 85
and 87 is not significantly affected by this internal offset when measuring inputs that are within 5 % to 100 % of the
selected range. When the rms value of the two values (5 % of range and internal offset) is calculated, the effect is
minimal as shown in the following example where 20.0 = 5 % of 400 mV range, and 2.5 is the internal offset: RMS =
SQRT[(20.0)
2
+ (2.5)
2
] = 20.16. If you use the REL function to zero the display when using the ac functions, a
constant error that is equal to the internal offset will result.
4. Frequency range: 1 kHz to 2.5 kHz.
5. Below 10 % of range, add 16 counts.
AC Voltage Specifications (Model 83)
Function Range Resolution Accuracy
1
50 Hz - 60 Hz 45 Hz - 1 kHz 1 kHz - 5 kHz
K
2
400.0 mV
4.000 V
40.00 V
400.0 V
1000 V
0.1 mV
0.001 V
0.01 V
0.1 V
1 V
±(0.5 % + 4)
±(0.5 % + 2)
±(0.5 % + 2)
±(0.5 % + 2)
±(0.5 % + 2)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
±(1.0 % + 4)
±(2.0 % + 4)
±(2.0 % + 4)
±(2.0 % + 4)
±(2.0 % + 4)
3
unspecified
1. For extended use at high RH, change the 400 mV and 4.0 V ac accuracy specification to ± (1.5 % + 4 counts) for
45 Hz to 1 kHz and ± (3.0 % + 25 counts) for 5 kHz to 20 kHz.
2. Below a reading of 200 counts, add 10 counts.
3. Frequency range: 1 kHz to 2.5 kHz.
DC Voltage, Resistance, and Conductance Specifications
Accuracy
1
Function Range Resolution Model 83 Model 85 Model 87
L
4.000 V
40.00 V
400.0 V
1000 V
0.001 V
0.01 V
0.1 V
1 V
±(0.1 % + 1)
±(0.1 % + 1)
±(0.1 % + 1)
±(0.1 % + 1)
±(0.08 % + 1)
±(0.08 % + 1)
±(0.08 % + 1)
±(0.08 % + 1)
±(0.05 % + 1)
±(0.05 % + 1)
±(0.05 % + 1)
±(0.05 % + 1)
F
mV
400.0 mV 0.1 mV ±(0.3 % + 1) ±(0.1 % + 1) ±(0.1 % + 1)
e
nS
400.0 Ω
4.000 kΩ
40.00 kΩ
400.0 kΩ
4.000 MΩ
40.00 MΩ
40.00 nS
0.1 Ω
0.001 kΩ
0.01 kΩ
0.1 kΩ
0.001 MΩ
0.01 MΩ
0.01 nS
±(0.4 % + 2)
2
±(0.4 % + 1)
±(0.4 % + 1)
±(0.7 % + 1)
±(0.7 % + 1)
±(1.0 % + 3)
±(1.0 % + 10)
±(0.2 % + 2)
2
±(0.2 % + 1)
±(0.2 % + 1)
±(0.6 % + 1)
±(0.6 % + 1)
±(1.0 % + 3)
±(1.0 % + 10)
±(0.2 % + 2)
2
±(0.2 % + 1)
±(0.2 % + 1)
±(0.6 % + 1)
±(0.6 % + 1)
±(1.0 % + 3)
±(1.0 % + 10)
1. For extended use at high RH, change the 400 mV and 4.0 V ac accuracy specification to ± (1.5 % + 4 counts) for
45 Hz to 1 kHz and ± (3.0 % + 25 counts) for 5 kHz to 20 kHz.
2. When using the REL ∆ function to compensate for offsets.

Fluke 80 Series III Specifications

General

Brand	Fluke
Model	80 Series III
Category	Multimeter
Language	English
