Vibration Tester
Start the Tester
11
Table 5. Accessory Connectors
Item Connector Description
# Tachometer Connects the Tachometer
$ USB
Connects the Tester to the PC
using a USB cable
% Sensor
Optional connector for single
axis Sensor
& Sensor Connects the triaxial Sensor
Start the Tester
Note
• Before using the Tester for the first time,
charge the battery for at least three hours.
For charging procedure, see “Battery.”
• Before using the Tester, make sure that
there is sufficient battery charge and free
memory.
Push * to turn on the Tester. At power up, the Tester
displays the remaining memory and the battery status.
The battery status icon . and the set date and time
appear at the top of the display.
Note
The first time you turn the Tester on, it displays
the Settings screen. It is important to enter the
correct information into the setup fields before
you start a test, especially the power line
frequency. For more information, see
“Instrument Setup” section.
To Next Page
