Fluke 810 - Page 24

810
Getting Started
18
Table 6. Tester Settings
Option Description
Power line
freq
Set the ac power line frequency to 60Hz
or 50Hz. The diagnostic quality of a test
depends on the correct selection of the
ac power line frequency.
Date format Set the Date format as d/m/y or m/d/y
Date Scroll and set the Day, Month, and Year
fields
Time format Set the Time format as 12Hr or 24Hr
Time Scroll and set the Hour, Minute, and AM
or PM fields
Beeper Set the Beeper as ON or OFF
Backlight
brightness
Set the display brightness as High or
Low
Power save Scroll and select to set the delay time for
the Sleep Mode. If no key is pushed
during the set time, the Tester goes into
the sleep mode to save battery power.
Any key push cancels the sleep mode
and resumes normal operation.
Backlight
duration
Scroll and select to set the delay time for
the display backlight. If no key is pushed
during the set time, the backlight turns off
to save battery power. The backlight
turns on when any key is pushed.
Time
waveform
capture
Scroll and select the number of
measurements where the time waveform
is to be captured. The Tester captures
and stores the time waveform data for
the selected number of measurements.
Note
Capture and review of time waveform
data is useful in advanced vibration
analysis, but keep in mind that data
capture uses a significant amount of
memory. Captured time waveforms can
only be viewed in the Viewer Software,
not the Tester.
Units Scroll and select a unit of measurement
as US or metric. Also select the units for
the vibration amplitude. VdB and in/sec
for US. VdB* indicates VdB Europe and
mm/sec for Metric.
