Fluke 867B - Page 28

867B/863
Users Manual
1-14
TTL
3V
CMOS
5V
CMOS
2
Hz
20
Hz
2
kHz
18.75
kHz
200
Hz
Set Up
Self
Test Exit
Next
Item
Restore
All
Save
Set Up
rita0350.eps
Figure 1-7. LOGIC Test, Component Test, Set Up
Duty
Cycle
Period Exit
Pulse
Width
Min Max
Off
Restart Exit
Wave
Scale
Exit
Run
Pause
Auto
Manual
rita0360.eps
