Fluke 87 User Manual

Model 87 & 89 Series IV
Users Manual
2-6
Table 2-1. Rotary Switch Selections
Position Rotary Switch Function % Blue Key Function
\
AC voltage measurement from 0 V to 1000.0 V dB over AC, AC over dB
,
AC millivolt measurement from 0 mV to 1500.0 mV dB over AC, AC over dB
$
DC voltage measurement from 0 V to 1000.0 V AC over DC (AC in primary display, DC in secondary
display), DC over AC, ac+dc
m
DC millivolt measurement from 0 mV to 3000.0 mV AC over DC (AC in primary display, DC in secondary
display), DC over AC, ac+dc
j
Resistance measurement from 0 Ω to 30.000 MΩ Continuity test
Conductance measurement from 0 nS to 50.00 nS
z
Capacitance measurement from 0.001 nF to 50 mF Diode test
w
Temperature measurement Toggles between °C and °F.

Fluke 87 Specifications

General

True RMS	Yes
Max Voltage AC/DC	1000 V
AC Voltage Range	0.1 mV to 1000 V
DC Voltage Range	0.1 mV to 1000 V
Resistance Range	0.1 Ω to 50 MΩ
Safety Rating	CAT III 1000 V, CAT IV 600 V
Weight	355 g
Diode Test	Yes
Continuity Test	Yes
Max Current AC/DC	10 A
AC Current Range	0.1 μA to 10 A
DC Current Range	0.1 μA to 10 A
Capacitance Range	10.00 nF to 10.00 mF
Frequency Range	0.01Hz to 200kHz
Battery Type	9V
Battery Life	400 hours typical, without backlight
Dimensions	201 x 98 x 52 mm
Temperature Measurement	-200.0 °C to 1090 °C (-328.0 °F to 1994 °F)
