Model 87 & 89 Series IV
Users Manual
7-8
Function Range Resolution Accuracy
Resistance
1
500.00 Ω 0.01 Ω 0.05 % + 10
3,4
5.0000 kΩ 0.0001 kΩ 0.05 % + 2
50.000 kΩ 0.001 kΩ 0.05 % + 2
500.00 kΩ 0.01 kΩ 0.05 % + 2
5.0000 MΩ 0.0001 MΩ 0.15 % + 4
2
30.000 MΩ 0.001 MΩ 1 % + 4
2
Conductance 50.00 nS 0.01 nS 1 % + 10
1. For the 5,000 count mode, divide the number of least significant digits (counts) by 10.
2. For relative humidity greater than 70 %, resistance accuracy is 0.5 % over 1 MΩ and 2.5 % over 10 MΩ.
3. In RF field of 3 V/m, add 45 counts from 470 to 1000 MHz.
4. Using relative mode (REL ∆) to zero residual reading.
