DSP-4000 Series
Getting Started Guide
14
Turning On the Test Tool
To turn on the test tool, turn the rotary switch from OFF to
any one of the available modes. The power-up screen,
which appears for about 3 seconds, shows the software,
hardware, and test standards versions for the main and
remote units. (The remote information is shown only if the
remote is on and connected to the main unit.)
During the power up cycle the test tool performs a self
test. If an error message appears, refer to “If the Test
Tool Fails” in Chapter 8 of the users manual on the
DSP-4000 Series Manual CD.
Selecting a Language
The test tool displays a language selection screen if a
language has not been selected since the tool left the
factory. Use U D to select a language; then press E.
You can change the selected language at any time in
SETUP mode.
Quick Configuration
Table 4 describes the settings you will most likely need to
change to configure the test tool for your needs.
To access the settings, turn the rotary switch to SETUP.
Use $ Page Down and U D to locate and highlight
a setting; then press E to see the available choices.
