DSP-4000 Series
Getting Started Guide
2
Standard Accessories
A DSP-4000 Series test tool comes with the following
accessories. If the test tool is damaged or something is
missing, contact the place of purchase immediately.
• 1 DSP-4000SR, DSP-4100SR, or DSP-4300SR
remote unit
• The following link interface adapters:
◊ With the DSP-4000 and DSP-4100: 2
DSP-LIA011 Basic Link Adapters for Cat 5E and
2 DSP-LIA012 Channel Adapters for Cat 6
◊ With the DSP-4000PL: 2 DSP-LIA101
Permanent Link Adapters for Cat 6 and 2
DSP-LIA012 Channel Adapters for Cat 6
◊ With the DSP-4300: 2 DSP-LIA101 Permanent
Link Adapters for Cat 6, 1 DSP-LIA012 Channel
Adapter for Cat 6, and 1 DSP-LIA013
Channel/Traffic Adapter for Cat 6
• 2 AC adapter/chargers 120 V (US only) or universal
adapter/chargers and line cords (outside North
America)
• 1 Memory card reader (DSP-4100, DSP-4300)
• 1 16 MB memory card (DSP-4100, DSP-4300)
• 1 Memory card carrying case (DSP-4100, DSP-4300)
• 2 NiMH battery packs (installed)
• 2 Headsets
• 1 DSP-4000 Calibration Module
• 1 RJ45 to BNC adapter
• 1 PC serial interface (EIA-232C) cable
• 2 Carrying straps
• 1 LinkWare software CD
• 1 DSP-4000 Series Manual CD (includes complete
users manual)
• 1 DSP-4000 Series Getting Started Guide
• 1 Warranty registration card
• 1 Soft carrying case
If you purchased optional Fiber Test Adapters, refer to the
Fiber Test Adapter users manual for a list of fiber
accessories.
