Fluke DSX-600 CableAnalyzer - CableAnalyzer Comparison Guide; DSX-600 Model Features Overview

26
Feature DSX-600 CableAnalyzer ™
DSX-5000 CableAnalyzer ™ DSX-8000 CableAnalyzer ™
Description
Essential Cat 6A and Class E
A
copper tester
Cat 6A and Class F
A
copper tester
Fastest, most accurate Cat 8 and Class I/II
copper cable tester
Cat 3 – Cat 6A / Class E
A

 
Cat 6A / Class F
A
X
 
Cat 8 / Class I/II
X
X

Maximum Frequency 500 MHz
1000 MHz 2000 MHz
Autotest Time
10 sec Class E
A
/Cat 6A
9 sec Class E/Cat 6
10 sec Class E
A
/Cat 6
A
9 sec Class E/Cat 6
16 sec Cat 8 / Class I/II
8 sec Class E
A
/Cat 6A
7 sec Class E/Cat 6
Shield Integrity Test

 
Permanent Link Adapter Optional
 
Advanced Fault Info Troubleshooting
X
 
PoE Resistance Unbalance
X
 
Integrated Alien Crosstalk Capability
X
 
Coax Adapters Optional
Optional Optional
M12 Adapters Optional
Optional Optional
Patch Cord Adapters
X
Optional Optional
Fiber – OLTS, OTDR & Inspection
X
Optional Optional
The modular Versiv family Future-ready design supports up to TIA Cat 8
and ISO Class I/II, singlemode and multimode ber loss and OTDR testing
plus inspection. Advanced diagnostics instantly pinpoint the cause and location of
cable faults in plain language. Both Versiv copper cable testers provide measurements
to support advanced technologies, including Alien Crosstalk for NBASE-T and other
applications, and Resistance Unbalance for Power over Ethernet (PoE).
The DSX-600 provides essential Cat 6A and Class E
A
Copper Certication featuring ten
second test times and advanced user interface. Manage jobs and testers from any smart
device over Wi-Fi with LinkWare™ Live. Features legendary Fluke Networks reliability
backed by worldwide support.
