FOM/FOS
Service Information
6
J1 (Red)
J2 (Black)
U1 Pin 7, (V
det
)
U1 Pin 5, (Analog GND)
FPM1-00-0100
eq1f.eps
Figure 1. FOM Calibration Measurement and Adjustment Points
