Fluke II Series User Manual

29
Connecting to a UUT (cont.)
B.
A.
UUT
HI
LO
A
HI
LO
GUARD
INPUT
SENSE
4-WIRE
HI
HI
LO
LO
HI
SENSE
V
AUX
CURRENT
V-GUARD
GROUND
WIDEBAND
Calibrator
Keep the SENSE leads as short as possible.
Be careful not to exceed the capacitive load limit of
1000 pF up to 220V, 600 pF 220 to 1100V. (1000 pF
with 5725A Amplifier.)
TRIAXIAL CABLE
UUT
HI
LO
A
HI
LO
GUARD
INPUT
SENSE
4-WIRE
HI
HI
LO
LO
HI
SENSE
V
AUX
CURRENT
V-GUARD
GROUND
WIDEBAND
Calibrator
TRIAXIAL CABLE
EX SNS
: OFF
EX GRD
: OFF
EX SNS
: ON
EX GRD
: OFF
OUTPUT
V A
Ω
OUTPUT
V A
Ω
Ω
Ω
Ω
Ω
TRIAXIAL CABLE
NOTE
AC Voltage >10 kHz

Fluke II Series Specifications

General

True RMS	Yes
Temperature	-40 °C to 400 °C
Continuity	Yes
Diode Test	Yes
Safety Rating	CAT III 600V
Voltage DC	600V
Voltage AC	600V
Current DC	10A
Current AC	10A
Resistance	40MΩ
Battery Life	400 hours
Warranty	3 years
