Fluke II Series - Fuse and Line Voltage

4
P Fuse and Line Voltage
The correct fuse type for each voltage selection is
indicated on the rear panel as shown in the
following figure.
VOLTAGE
SELECTION
FUSE-F1
T 125A
250V
(SB)
100V
S2 S3 S4
110V
115V
120V
VOLTAGE
SELECTION
FUSE-F1
T 125A
250V
(SB)
200V
S2 S3 S4
220V
230V
240V
CAUTION FOR FIRE PROTECTION REPLACE ONLY
WITH A 250V FUSE OF INDICATED RATING.
VOLTAGE
SELECTION
FUSE-F1
T 125A
250V
(SB)
100V
S2 S3 S4
110V
115V
120V
VOLTAGE
SELECTION
FUSE-F1
T 125A
250V
(SB)
200V
S2 S3 S4
220V
230V
240V
CAUTION FOR FIRE PROTECTION REPLACE ONLY
WITH A 250V FUSE OF INDICATED RATING.
Line Power Label and Switch Locations
