Fluke LinkRunner Pro User Manual

General Specifications
Media Access 10BASE-T, 100BASE-TX, 1000BASE-T (IEEE 802.3), and PoE (IEEE 802.3af)
Cable Tests Pair lengths, opens, shorts, splits, crossed, straight through, Wireview
TM
cable ID
Tone Generator IntelliTone digital tone: [500 KHz]
Analog tones: [400Hz, 1KHz]
UI Interface B&W, 2”x 1” display, Link LED
UI Control / Data Entry Five push-buttons for selection of icons and navigation of menus
Power Button On/Off
Ports (2) RJ45s: network test port, loop-back wire map port
Application Port Mini-USB
Battery
4 AA batteries 4 AA batteries or optional Lithium Ion battery pack with 15VDC
1.2A AC adaptor accessory
Physical Security Kensington Lock
Warranty One year
Mechanical Electrical Specifications
Weight 10 oz. with 4 AA Alkaline batteries
8.4 oz. with 4 AA LI batteries
Dimensions 5.3” height x 3.1” width x 1.3” depth
13.3cm height x 8cm width x 3.2cm depth
RJ-45 Network Port Designed to withstand a maximum of 100V
Security
Operational Security IEEE 802.1X option for network authentication
Environment Specifications
Operating Temperature 10 – 40 degrees C
Storage Temperature -20 to 60 degrees C
Operating Humidity 95% relative humidity (non-condensing)
Vibration Requirements
Meets requirements for MIL-PRF-28800F for Class 2 random
vibration
Connection To Public Telephone
Network
Should never be connected to the public telephone network
Artisan Technology Group - Quality Instrumentation ... Guaranteed | (888) 88-SOURCE | www.artisantg.com

Fluke LinkRunner Pro Specifications

Operating Environment

operating temperature	10 – 40 degrees C
storage temperature	-20 to 60 degrees C
operating humidity	95% relative humidity (non-condensing)

Power

battery type	4 AA batteries
RJ-45 network port maximum voltage	100 V
tone generator digital tone frequency	500 KHz

Weight and Dimensions

weight with 4 AA Alkaline batteries	10 oz
weight with 4 AA LI batteries	8.4 oz
height	5.3 inches
width	3.1 inches
depth	1.3 inches
