MicroMapper
User’s Manual
4
MICROMAPPER Controls and LEDs
1
-
23
-
64
-
57
-
8 SHIELD
SHORT
TONER
TEST
REVERSED
MISWIRE
SPLIT PAIRS
LOW BATTERY
REMOTE
M
ICRO
M
APPER
atx02f.eps
Figure 1. MICROMAPPER Network Cable Tester
Table 1. M
ICROMAPPER Controls and LEDs
Item
Number
Description
A Pair and Shield Indicator LEDs
B Toner LED
C TEST button
D REMOTE Adapter with RJ45 Jack
E RJ45 Jack
F Off/Cable/Toner Switch
G Fault LEDs
H Low Battery LED
