ProcessMeter™
Specifications
41
Ohms Measurement
Range Resolution Measurement Current Accuracy, ±(% of Reading + Counts)
400.0 Ω 0.1 Ω 310 μA 0.2 % + 2
4.000 kΩ 0.001 kΩ 31 μA 0.2 % + 1
40.00 kΩ 0.01 kΩ 2.5 μA 0.2 % + 1
400.0 kΩ 0.1 kΩ 250 nA 0.2 % + 1
4.000 MΩ 0.001 MΩ 250 nA 0.35 % + 3
40.00 MΩ 0.01 MΩ 125 nA 2.5 % + 3
Overload protection: 1000 V
Open circuit voltage: <3.9 V
