Fluke ScopeMeter 123 - Page 139

123
Service Manual
8-14
Reference
Designator
Description Ordering
Code
Remarks
C609 CER.CAP. 2KV +-5% 33PF 5322 126 14047
C610 CER CAP X5R 1206 10% 1UF 5322 126 14089
D401 * LOW VOLT ADC TDA8792M/C2/R1 5322 209 14837
D451 * LOW VOLT ADC TDA8792M/C2/R1 5322 209 14837
D471 * D-ASIC MOT0002 5322 209 13139
D474 * 8M FEPROM
AM29LV800B-120EC, or HN29WT800T , or
M5M29FB800VP-120, or equivalent.
5322 209 15199
D475 * 128K8SRAM M5M51008AVP10VLL MIT 5322 209 14844
D480 * 4X2-INP OR 74LVC32APW 4022 304 10771
D531 * 8-INP MUX 74HC4051D PEL 5322 209 61483
H495 PE BUZZER PKM13EPP-4002 MUR 5322 280 10311
H521 IR LED SFH409-2 SIE 5322 130 61296
H522 PHOTODIODE OP906 OPT 5322 130 10777
K171 DPDT RELAY ASL-1.5W-K-B05 5322 280 10309
K173 DPDT RELAY DSP1-L-1,5V MAT 5322 280 10312
K271 DPDT RELAY ASL-1.5W-K-B05 5322 280 10309
L181 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L182 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L183 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L281 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L282 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L283 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L481 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L501 CHOKE 33UH TDK 5322 157 10994
L562 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
L563 CHIP INDUCT. 47UH 10% TDK 4822 157 70794
