TS25D Test Set
Users Guide
6 If the test set is off-hook, press the SEL key to dial
the selected entry.
Configuring the Test Set
This section tells you how to use the menus to
configure the test set.
Settings Screen
To access the Settings screen:
1 Set the slide switch to the Talk (T) or Monitor (M)
position.
2 Press the SEL key.
3 At the Main menu, highlight SETTINGS with the
arrow keys and press the SEL key. You will see a
sub-menu with the following three selections:
TONE/PULSE, TIMING and SYSTEM
CONFIGURATION. These menu items provide
access to the selections for configuring the test set.
Tone/Pulse Dialing
To set Tone or Pulse dialing:
1 At the Main menu, highlight SETTINGS with the
arrow keys, then press the SEL key.
2 Highlight Tone/Pulse with the arrow keys, then
press the SEL key, or press 1 on the keypad.
3 Press either 1 for TONE or 2 for PULSE. The Tone or
Pulse icon is displayed at the top of the screen (see
Figure 2).
Timing
Use the Timing option to set the Pause duration and
the Flash duration.
Pause Duration
To set the Pause duration:
1 Set the slide switch to the Talk (T) or Monitor (M)
position.
2 From the Settings screen, highlight TIMING with
the arrow keys, then press the SEL key, or press 2
on the keypad.
3 Press 1 - PAUSE DURATION.
4 Highlight the desired pause seconds with the
arrow keys, then press the SEL key, or press one of
the following keys on the keypad:
1 - 3 seconds
2 - 4 seconds
3 - 5 seconds
The default pause length is 4 seconds.
Flash Duration
To set the hook flash duration:
1 Set the slide switch to the Talk (T) or Monitor (M)
position.
2 From the Settings screen, highlight TIMING with
the arrow keys, then press the SEL key, or press 2
on the keypad.
3 Press 2 - FLASH DURATION.
4 Highlight the desired flash seconds with the arrow
keys, then press the SEL key, or press one of the
following keys on the keypad:
1 - 400 ms
2 - 600 ms
3 - 800 ms
The default hook flash duration is 600 ms.
One flash is performed for each press of the FLSH key.
Holding the FLSH key down does not repeatedly flash
the switch hook.
